Technical Parameters
| Valve Body Material | SS304/SS316L | |
| Seat Seal Material | FKM, NBR in option | |
| Vacuum Range | 10⁵-6.7×10⁻⁵ Pa | |
| Leak Rate | 1.3×10⁻⁵ Pa. L/s | |
| Cycles Until Service | 100,000 Times | |
| Angle Opning | 0-90 Degree | |
| Temperature Range | FKM Seat Seal | -30°C to 150°C (about) |
| NBR Seat Seal | -25°C to 80°C (about) | |
| Operated | Manual, Pneumatic Actuator, Electric Actuator | |
| Compressed Air | 0.4-0.8Mpa | |
| Opening/Close Speed | Aluminium Actuator | ≤3S |
| Electric Actuator on-off type | Standard 30 S. 10S, 15S option | |
| Solenoid Voltage | AC220V, 50Hz, 6W or on request | |
| Standard Electric Actuator | On-off type | |
| Avaible with Position Indicator | Optional signal feedback | |
